Plastic Dustbin Four Shaft Shredder , Automatic Medical Waste Shredder

Plastic Dustbin Four Shaft Shredder , Automatic Medical Waste Shredder

Brand Name: Joful
Model Number: S-600/700/800/1000 / T-400/600/800/1000/1200/1500/2000 ..
MOQ: 1 set
Price: Negotiable
Supply Ability: 15-35 sets per month
Detail Information
Place of Origin:
CN
Certification:
CE
Blade Material:
Sicr Cris H13 Ld SKDII D2 Customizable
Product Name:
Shredding Machines For Waste Drum,bucket,barrel,dustbin,dustbin Shredder,plastic Barrel Shredding
Voltage:
Customizable
Application:
Drum , Dustbin , Wood , Plastic ...
Horse Power:
20 HP *2
Output Size:
10-100mm
Machine Weight:
Base On Crushing Demand
Installation:
Engineers Available To Service Abroad
Packaging Details:
Film , EPE Foam , Export Wooden Box ,or per cients' requirement
Supply Ability:
15-35 sets per month
Highlight:

plastic drum shredder

,

medical waste shredder

Product Description



Four Shaft Automatic Drum Shredder Machine , Plastic Dustbin Shredder Machine , Hard Drum Shredder





Application of drum shredder / plastic dustbin shredder


  1. MF series Drum / plastic dustbin Shredder Machines have variety functions and advantages.
  2. They have advantages in strong generability, standardization and modularization design, high interchangeability for their components.
  3. Their assistant blades are refined by forging and milling process and their main blades are made of special alloy steel with high strength and strong anti wear.
  4. The drive part takes advantage of gears transmission in the middle to make them rotate at different speeds. It’s convenient to disassemble the screen.





Quick details


1. Lead time - 48 working days
2. Payment Term - 30% advanced payment once upon signing the contract,70% balance payment before delivery.
3. Installation - Whole set machine delivery out,no need abroad installation. If necessary,can support abroad installation also or offer assembly video
4.Warranty - 15 months (account from the day client receive the machine). If there's non-human damage but the machine has quality problem,we will offer the spare part for free,and if complicated problem we can send engineer to there to fix ,all costs are undertake by factory side




Typical Applications


  • Bucket products - plastic bucket, metal drum, paint bucket, intermediate -bulk container (IBC) and dustbin
  • Wastes -  household waste, medical waste, kitchen waste, industrial waste, park waste
  • Plastic products - plastic bottle, plastic frame, plastic block, plastic can
  • Metal products - aluminum profile, oil filter, car shell, pop-top can, metal cans,PET bottle bale,aluminum cans bale
  • Paper - newspaper bale, cardboard bale, corrugated paper bale,cartons
  • E Scrap - Waste Electronics ,IT Equipment,Waste Circuit Board,Hard drive,computer,printer etc



Standard Models for general reference

Model MF600 MF800 MF1000 MF1200 MF1600
Blade Rotating Dia 320mm 320mm 360mm 360mm 400mm
Main Blade Qty 24 32 40 48 64
Main Motor Power 15*2 kw 18.5*2 kw 22*2 kw 30*2 kw 45*2 kw
Machine Weight kg 3500 kg 5000 kg 6500 kg 8000 kg 9000 kg
Machine Dimensions mm 2960*1000*2300 3160*1070*2400 3360*1170*2500 3560*1200*2550 3760*1260*2600

(We  customize each model per clients' shredding demand , One size shredder does not fit all application !)





With more than 20 years design&manufacturing experience on blades,cutters




Q. What's the best price of your shredder machine ?
A. Depends on
1. Which Material you need to shred?
2. What's your output demand per hr  ?
3. What's your output size request ?



Q. How much does a shredder weigh?

A. The weight of a shredder truly depends on its configuration. Each application (plastic, metal ,wood, paper, etc.) has a configuration that works best. The various rotor types, blades systems and reinforced machine walls can all play a big part in the machine’s weight. Joful shredders are designed specifically with your application in mind. One size shredder does not fit all application !
